上海翻譯公司完成企業技術接入規范英文翻譯1 Foreword
The purpose of this file aims to define the general external service interface of BSP enterprise service platform, quickly integrate the big customers’ proprietary system, connect the information flow between big customers and Shunfeng System, and realize the integration of the integral logistics supply chain, so as to reach the win-win results for Shunfeng and customers.
2 Description of interface specification
Unify using UTF-8 coded XML message through external service interface; interface communication protocol supports WEBSERVICE, HTTP/POST and FTP; currently WEBSERVICE protocol is used mainly.
General external service interfaces are classified as active access interface and external push interface. The external push interface based on FTP protocol does not need corresponding response message. Other protocols require correspond requests and corresponding messages. The following text defines the format and rules to be observed by the general external service interface message.
² Request message
<Request service="service name" lang="zh-CN">
<Head>customer ID card number, check code</Head>
<Body>Request data XML</Body>
</Request>
Key rules
a) Service property and HEAD element predefined the service name, customer card number and check code. Combining with the customer IP address on request can satisfy the verification of system functional jurisdiction only by analyzing HEAD elements. The condition without functional jurisdiction needs no further analysis of internal Body data, which greatly improves the performance of blocking illegal access.
b) Customer ID card number and check code shall be unified by the allocation of Shunfeng.
c) long property is used for support the international request with the default value of zh-CN.
² Response message：
<Response service="service name">
<Head>OK|ERR</HEAD>
<BODY>Normal response message XML</BODY>
<ERROR code="NNNN">Wrong detailed message </ERROR>
</Response>
Key rules
a) Head element value is OK or ERR; OK represents normal transaction and ERR represents system or business exception; as for batch transaction settings, partial transaction exception must return OK value; exception transaction records must be indicated in returning BODY to avoid the next complete resending.
b) Return to BODY element while Head element value is OK; return to ERROR element while Head value is ERR; BODY and ERROR elements cannot coexist together.
c) “Code property value” in ERROR element is four-digit number. The description of error code refers to the last part of the reference files.
² Recording number of batch transaction is limited under 20 (referring to Shunfeng Website). Special business may define the limit not supporting the batch transaction or batch recorded number less than 20 itself.
² The definition of data elements of request or normal response data XML shall abide by the principle of separating defining necessary fields (including default value field), optional fields and extended fields. Meanwhile, fields shall be defined through the element property with the field value limited under 200 characters (less than 50 Chinese characters); necessary fields shall be defined through the element property; optional fields shall be defined “data element name +Option” element through the property under the data element; extended fields shall be defined by reserving the property of element <Extra> under the data element; the number of necessary fields shall be controlled under 10 as possible.
<Order id="XXXX" …>
<OrderOption payment="XXXX" …/>
<Extra e1="XXXX" …/>
</Order>
The element property of OrderOption and value are defined by the specific business data. Extra element supports 20 properties to the utmost; property names are e1,…,e20, only supporting character string value.
² Try the utmost to reduce the field amount required for delivery in interface message through individualization service configuration of customers. For example, add the code of goods-delivering points in order message, allocate the monthly account and other data in the way of backstage-based customer + code of goods-delivery point, thus avoid delivering the affiliated monthly account in interface message.
² Request and response message elements shall be named by word order headed by capital letters, like “OrderResponse”; property name shall use small letters wholly, like “orderid”; subelements shall be expressed by using “/” path in the defined table, like “outeTrackingResponse/Route”.
General external service interface has defined the express-type service interface presently; the reference address refers to the following.
Http://bsp-oip/sf-express.com/bsp-ois/ws/expressService
3 Express-type service interface
3.1 Oder-placing (including filtering)
3.1.1 Function description
Order-placing interface may provide the following three functions according to the customers’ requirements.
1） Customer system places order to Shunfeng in a unified way.
2） Allocate transport number for order number.
3） Filtering order
3.1.2 vDefinition of dominant message at interfaces
Service name OrderService Batch transaction limiting Not supporting Interface type Access Protocol type WEBSERVICE Interface method public String sfexpressService(String XML); Dataelement<request> Order Name of necessary field Types（restricted） Default value Description orderid String(64) Customers’ order number, suggested as English letters +YYMMDD（date）+serial number,TB1207300000001 express_type String(5) Standard express Type of express-type products
1 Standard express
2 Shunfeng preferencej_company String(100) _SYSTEM Sender’s company name, “_SYSTEM” means getting from system configuration if not provided. j_contact String(30) _SYSTEM Sender’s contact personnel, “_SYSTEM” means getting from system configuration if not provided. j_tel String(20) _SYSTEM Sender’s phone number, “_SYSTEM” means getting from system configuration if not provided. j_address String(150) _SYSTEM Sender’s detailed address, including prince, city and districts, for example, F10, Wangji Business Mansion, 11th Street, Xinzhou, Futian District, Shenzhen City, Guangdong Province, “_SYSTEM” means getting from system configuration if not provided. d_company String(100) Receiver’s company name d_contact String(30) Receiver’s contact personnel d_tel String(20) Receiver’s telephone number d_address String(150) Receiver’s detailed address, for example, F10, Wangji Business Mansion, 11th Street, Xinzhou, Futian District, Shenzhen City, Guangdong Province, parcel_quantity Number(5) 1 Package number shall be provided if producing transport order number. A package corresponds to a transporting order number. Data must be correct. pay_method Number(1) _SYSTEM Type of payment: 1. Paid by sender; 2 Paid by receiver;3 Paid by the third party. The default value is 1. “_SYSTEM” means getting from system configuration if not provided. j_province String(30) _SYSTEM Filling requirement of the sender’s located province name field must be standard province name, like Guangdong Province j_city String(100) _SYSTEM Filling requirement of the sender’s located city name field must be standard city name, like Shenzhen City. d_province String(30) Filling requirement of the receiver’s located province name field must be standard province name, like Guangdong Province. d_city String(100) Filling requirement of the receiver’s located city name field must be standard city name, like Shenzhen City. Data element
<Response>OrderResponse Field name Type（restricted） Not-empty or not Description orderid String(64) No Order number mailno String(20) Transporting order number may be affiliated with order numbers like, integrated parts and sub-parts,separated by comma. origincode String(10) No Code for originally-sending place destcode String(10) No Destination code filter_result Number(2) Filtering order results: 1. Artificial selection; 2 collectable; 3 Uncollectable remark String(100) 1. Receiver exceeding 2. Sender exceeding 3. Other reasons
3.1.3 Optional field information
Value-added service value descriptionData elements Order/OrderOption Field name Type（Restricted） Description custid String(20) Monthly card account number SYSTEM configurable template String(30) Template selection j_shippercode String(30) Sender code d_deliverycode String(30) Receiver code cargo String(4000) Cargo name; maybe have variant articles; use comma to separate cargo names for variant articles. For example, mobile phone, IPAD, charger. Require producing electronic transporting bill. This field must be delivered. cargo_count String(4000) Cargo quantity; be separated with comma for variant cargos, corresponding to the described cargo, for example, 2,1,3. cargo_unit String(4000) Cargo unit; be separated with comma for variant articles, corresponding to the described cargo, for example, piece, set, book. cargo_weight String(4000) Cargo weight; be separated with comma for variant cargos, corresponding to the described cargo, for example, 1.5,1.0,3.0 cargo_amount String(4000) Cargo unit price; be separated with comma for variant cargos, corresponding to the described cargo, for example, 1000,2000,1500 cargo_total_weight Number(10,2)
Total weight of order cargos, unit KG; if this value is provided, it shall be>0sendstarttime date The starting time of getting cargos, YYYY-MM-DD，HH24:MM:SS; for example: 2012-7-30 09:30:00. Default: system time for receiving order for the system mailno String(4000)
Mailing transporting order; only one main mailing order for an order; in case of integrated order and sub-order, please be separated by comma; the main order shall be placed at the first position. “755123456789,001123456789,002123456789“remark String(100) Remark Data element OrderOption/AddedService Field name Type（Restricted） Description name（ Defined corresponding relationship ） String(20) Value-added service, for example, COD, etc. value String(30) Value-added service value 1 Value1 String(30) Value-added service value 2 Value2 String(30) Value-added service value 3 Value3 String(30) Value-added service value 4 Value4 String(30) Value-added service value 5
Service NAME Description Remark Cash on delivery COD Value: cargo price; value1: customer value Support price INSURE Value: declared value MSG MSG Value: mobile phone number Packaging fee PKFEE Value: packaging fee SMS SMS Value is the mobile phone number and is the same as the receiver’s mobile phone number.
Value1 is the individualized words.Special support value SINSURE Value: service charge Special delivery
Special value-added service valueSDELIVERY
SADDSERVICEvalue : service charge
value: service charge
3.1.4 Extended field information
Follow the extended field specification
3.1.5 Application scenario XML example
² Scenario 1
Scenario description ：customer placing order
RequestXML：
<Request service=”OrderService” lang="zh-CN">
<Head>j_custid（customer card number ）,checkwork（check code ）</Head>
<Body>
<Order orderid=”Order number” express_type=”express type ”j_company=”Sender’s company name ”
j_contact=”sender’s contact personnel ”j_tel=”Contact telephone number”j_address=”Delivery address”d_company=”Receiver’s company name ”d_contact=”Receiver’s contact person ”d_tel=”Contact telephone number”d_address=”Receiver’s address” parcel_quantity=”Package number”pay_method=”Terms of payment ”>
<OrderOption custid=”Monthly settlement card account ”j_shippercode=”Sender’s code”d_deliverycode=”Receiver’s code”cargo=”Cargo name ”cargo_total_weight=”Total weight ”insurance_amount=”Declaration value ”sendstarttime=”Time inquiring getting cargo ” mailno=”Mail transporting order number ” remark=”Remark ”>
<AddedService name=”value-added service 1” value=”Value 1” value1=”Value 2” value2=”Value 3” value3=”Value 4”
value4=”Value 5”/>
<!-- ...// <AddedService>May be variant -->
</OrderOption>
<Extra e1=”extended field ” e2=”extended field ” e3=”extended field ” e4=”extended field ” e5=”extended field ” e6=”extended field ” e7=”extended field ” e8=”extended field ” e9=”extended field ” e10=”extended field ” e11=”extended field ” e12=”extended field ” e13=”extended field ” e14=”extended field ” e15=”extended field ” e16=”extended field ” e17=”extended field ” e18=”extended field ” e19=”extended field ” e20=”extended field ”/>
</Order>
</Body>
</Request>
Response XML：
Successfully treated order ：
<Response service=”OrderService”>
<Head>OK</Head>
<Body>
<OrderResponse orderid=”Order number” mailno=”Main order,Sub-order 1,Sub-order 2,…,Sub-order n” originCode=”Original delivered place code” destCode=”Destination code ” filter_result=”Filtering results ” remark=”Remark ”/>
</Body>
</Response>
Failed order treating：
<Response service=”OrderService”>
<Head>ERR</Head>
<ERROR code="NNNN">Detailed wrong message </ERROR>
</Response>
3.2 Confirming for order cargo delivery
3.2.1 Function description
This interface is used for customers to deliver the important information, like express weight, posting time, etc. through this interface to Shunfeng after delivering the cargos to Shunfeng Consignment
3.2.2 Definition of main message at interface
Service name OrderConfirmService Batch transaction limiting Not supporting Interface type Access Protocol type WEBSERVICE Interface method public String sfexpressService(String XML); Data element <Request> OrderConfirm Necessary field name Type (restricted) Default value Description orderid String(64) Order number mailno String(20) Mail transporting order number Data elements <Response > OrderConfirmResponse Field name Type (restricted) Non-empty or not Description orderid String(64) No Order number mailno String(20) No Mail transporting order number res_status Number(1) Remark: 1. Mismatch between order number and mail transporting order
2. Successful
3.2.3 Optional field information
Data elements OrderConfirm/OrderConfirmOption Field name Type (restricted) Description weight Number(10,2) Order weight, unit: KG
單位 KGvolume String(100) Length, width and height of delivered cargo shall be separated by comma; unit, CM, correct to 0.1.
3.2.4 Extended field information
Follow the extended field specification
3.2.5 Application scenario XML example
² Scenario 1
Scenario description ：
Request XML：
<Request service=”OrderConfirmService” lang="zh-CN">
<Head>custid（customer card number ）,checkwork（check code ）</Head>
<Body>
<OrderConfirm orderid=”Order number” mailno=”Mail transporting order number ”>
<OrderConfirmOption weight=”Express weight ” volume=”Lengh, width and height of delivered cargos ”/>
<Extra e1=”extended field ” e2=”extended field ” e3=”extended field ” e4=”extended field ” e5=”extended field ” e6=”extended field ” e7=”extended field ” e8=”extended field ” e9=”extended field ” e10=”extended field ” e11=”extended field ” e12=”extended field ” e13=”extended field ” e14=”extended field ” e15=”extended field ” e16=”extended field ” e17=”extended field ” e18=”extended field ” e19=”extended field ” e20=”extended field ”/>
</OrderConfirm>
</Body>
</Request>
Response XML：
Successfully confirmed order ：
<Response service=”OrderConfirmService”>
<Head>OK</Head>
<Body>
<OrderConfirmResponse orderid=”Order number” mailno=”Mail transporting order number ” remark=”Remark ”/>
</Body>
</Response>
Failed confirmed order ：
<Response service=”OrderConfirmService”>
<Head>ERR</Head>
<ERROR code="NNNN">Detailed wrong message </ERROR>
</Response>
3.3 Order filtering
3.3.1 Function description
Customer system sends the automatic filtering application through this interface to Shunfeng enterprise service platform, used for judging whether the sending and delivery address fall into the delivery scope of Shunfeng. The system can automatically judge whether the delivery address fall into the delivery scope of Shunfeng according to the addresses. If the receiver’s address falls into the scope, the mail can be delivered; otherwise, it cannot be delivered.
3.3.2 Definition of main messages at interface
Service name OrderFilterService Batch transaction limit <=5 Interface type Access Protocol type WEBSERVICE Interface method public String sfexpressService(String XML); Data element <Request> OrderFilter Necessary field name Type (restricted) Default value Description filter_type Number(1) 1 filtering type：1-automatic filtering (System judges according to the address base and returns the results); 2.- artificial filtering (System judges according to the address base. If it cannot judge whether the cargo is received or delivered, the system will produce the task of artificial judgment. The later work will be finished artificially. After completing the treating process, Shunfeng may automatically push to the customer system). orderid String(64) If
filter_type=2， it must be provided.
Customer order number
d_address
String(150)Receiver’s detailed address includes prince, city and district. F10, Wangji Business Mansion, 11th Street, Xinzhou, Futian District, Shenzhen City, Guangdong Province, Data elements <Response > OrderFilterResponse Field name Type (restricted) Non-empty or not Description orderid String(64) Order number; if the artificial filtering order shall be provided by Shunfeng. This order value shall be provided. filter_result Number(2) Not Filtering order results: 1. Artificial selection; 2 collectable; 3 Uncollectable origincode String(10) Code for originally-sending place destcode String(10) Destination code; if it is can be received and delivered, this item cannot be empty. remark String(100) 1. Receiver exceeding 2. Sender exceeding 3. Other reasons
3.3.3 Optional field information
Data elements OrderFilter/OrderFilterOption Field name Type (restricted) Default value Description j_tel String(20) Sender’s telephone number country String (50) CN Sender’s country
province
String (30)Sender’s located province must be standard province name, for example Guangdong Province (“Province” cannot be omitted.)
city
String (100)Sender’s located city must be standard city name, for example “Shenzhen City”(“City” cannot be omitted.)
county
String (30)Sender’s located county/district must be standard county/district name, for example “Futian District”(“District” cannot be omitted.) d_country String(50) CN Receiver’s country
d_province
String (30)Receiver’s located province must be standard province name, for example Guangdong Province (“Province” cannot be omitted.)
d_city
String (100)Receiver’s located city must be standard city name, for example “Shenzhen City”(“City” cannot be omitted.)
d_county
String (30)Receiver’s located county/district must be standard county/district name, for example “Futian District”(“District” cannot be omitted.)
j_address
String(150)Sender’s detailed address, for example, F10, Wangji Business Mansion, 11th Street, Xinzhou, Futian District, Shenzhen City, Guangdong Province, d_tel String(23) Receiver’s telephone number
3.3.4 Extended field message
None.
3.3.5 Application scenario XML example
² Scenario 1
Scenario description ：
RequestXML：
<Request service=”OrderFilterService” lang="zh-CN">
<Head>j_custid（customer card number ）,checkwork（check code ）</Head>
<Body>
<OrderFilter filter_type=”filtering type” orderid=”Order number” d_address=”Receiver’s address”>
<OrderFilterOption j_tel=”Sender’s telephonen number” j_address=”Sender’s address” d_tel=”Receiver’s telephone number”/>
</OrderFilter>
<!--...//including 5 as the maximum <OrderFiler>-->
</Body>
</Request>
Response XML：
Successfully treated filtering order：
<Response service=”OrderFilterService”>
<Head>OK</Head>
<Body>
<OrderFilterResponse orderid=”Order number” filter_result=”Whether it can be received or delivered ” origincode=”originally-delivering place code” destcode=”Destination code ” remark=”Remark ”/>
...
</Body>
</Response>
Failed treated filtering order：
<Response service=”OrderFilterService”>
<Head>ERR</Head>
<ERROR code="NNN">Detailed wrong message </ERROR>
</Response>
3.4 Artificial filtering results push
3.4.1 Functional description
If the customer gets the feedback results of: “3-to be confirmed” through the order-filtering interface, order number is provided and apply_type=2 when filtering order, then Shunfeng system will push the artificial filtering results to customer system when completing the artificial filtering order.
Customer system shall provide a HTTURL meeting the following specification s, so as to benefit Shunfeng to push the artificial filtering data to the customer system.
1) Shufeng pushes data to the customer system in the way of HTTP POST;
2) Encoding format of applying method: “application/x-www-form-urlencoded; charset=UTF-8”
3) The pushed filtering results are sent to the customer system in XML format though the way of POST;
4) A POST method can push 5 filtering data at the utmost;
5) Encode XRL for the xml contents (The character set shall be UTF-8);
6) After customer system receives the requires, it shall firstly decode the received contents in URL and get the corresponding XML value. Then it obtains the corresponding filtering data.
7) After the customer system correctly processes XML information, it responds information to Shunfeng. Considering the processing efficiency, listing order push shows the success or failure of batch.
3.4.2 Definition of main messages at interface
Service name OrderFilterPushService Batch transaction limit <=5 Interface type Push Protocol type HTTP Interface method None Data element <Request> OrderFilterResult Necessary field name Type (restricted) Default value Description orderid String(64) Order number; if the artificial filtering order shall be provided by Shunfeng. This order value shall be provided. filter_result Number(2) No Filtering order results: 1. Artificial selection; 2 collectable; 3 Uncollectable origincode String(10) Code for originally-sending place destcode String(10) Destination code; if it is can be received and delivered, this item cannot be empty. remark String(100) 1. Receiver exceeding 2. Sender exceeding 3. Other reasons mailno String(30) Mail transporting order number Data elements <Response > OrderFilterResultResponse Field name Type (restricted) Non-empty or not Description orderid String(4000) No Successfully received artificial filtering order number, in case of variant order number, they shall be separated by comma, for example”123,124” orderid_error String(4000) Unsuccessfully received artificial filtering order number, in case of variant order number, they shall be separated by comma, for example”123,124”Order number. The filtered data of this part will be regularly be-sent by Shunfeng.
3.4.3 Optional field message
None
3.4.4 Extended field message
None
3.4.5 Application scenario XML example
² Scenario 1
Scenario description ：
Request XML：
<Request service=”OrderFilterPushService”>
<Head>OK</Head>
<Body>
<OrderFilterResult orderid=”Order number” filter_result=”Whether it can be received or delivered ” origincode=”Original delivered place code”destCode=”Destination code ” remark=”Remark ”/>
<!--...//including 5 as the maximum <OrderFilterResult> -->
</Body>
</Request>
Response XML：
Successful Response ：
<Response service=”OrderFilterPushService”>
<Head>OK</Head>
</Response>
Failed Response ：
<Response service=”OrderFilterPushService”>
<Head>ERR</Head>
<ERROR code="NNNN">Detailed wrong message </ERROR>
</Response>
3.5 Route inquiry
3.5.1 Function description
Provide the customer system with the function of inquiring mail order route of the Shunfeng through interface. Support the requiring functions of single or batch route. In the batch requiring, 10 mail transporting order numbers shall not be exceeded in the batch requiring. For a same batch, only a same language mail transporting route shall be allowed.
Route requiring interface supports two requiring methods.
1) Requiring according to mail transpiring order number: provide the customer card number and mail transpiring order number in the inquiry request; the system only verifies the affiliation relationship of customers’ card number and all request mail transporting order number and the system only returns the mail order route information with correct affiliation relationship.
2) Requiring according to mail transpiring order number: provide the customer card number and mail transpiring order number in the inquiry request; the system only verifies the affiliation relationship of customers’ card number. As for the order number with correct affiliation relationship, find out the corresponding mail transporting order number and then return the route information of order corresponding to mail transporting order number. It is suitable for the customers placing orders through enterprise service platform.
3.5.2 Definition of main messages at interface
Service name RouteService Batch transaction limit <=10 Interface type Access Protocol type WEBSERVICE Interface method public String sfexpressService(String xml); Data element <Request> RouteRequest Necessary field name Type (restricted) Default value Description tracking_type Number(2) 1 Description of tracking types, tracking_type field：1-Track according to mail transporting order number, track_number in order nodes will be treated as per mail transporting order number; 2-Track according to order number and the track number shall in order points shall be treated as order number. tracking_number String(4000) Tracking number, if tracking_type=1, then the value shall be Mail transporting order number. If tracking_type=2, then the value shall be order number ; if variant order numbers exist, they shall be separated by comma, life “123,124,125” Data elements <Response > RouteResponse Field name Type (restricted) Non-empty or not Description mailno String(20) No Mail transporting order number orderid String(64) Order number Data elements <Response > RouteResponse/Route Field name Type (restricted) Non-empty or not Description accept_time Date No Route accepting time accept_address String(100) No Route accepting address remark String(150) No Specific Description opcode String(20) Operation code
3.5.3 Optional field message
None
3.5.4 Extended field message
None
3.5.5 Application scenario XML example
² Scenario 1
Scenario description: inquire according to mail transporting order number
Request XML：
<Request service=”RouteService” lang="zh-CN">
<Head>custid（customer card number ）,checkwork（check code ）</Head>
<Body>
<RouteRequest tracking_type=”tracking type ” tracking_number=”order number 1,order number 2,…,order number n”/>
</Body>
</Request>
Response XML：
Successfully inquired route：
<Response service=”RouteService”>
<Head>OK</Head>
<Body>
<RouteResponse mailno=”Mail transporting order number ” orderid=”Order number”>
<Route accept_time=”Route accepting time” accept_address=”Route accepting address” remark=”detailed description”
opCode=”Operation code”/>
<!--...//May including variant <Route>-->
</RouteResponse>
<!--...//Include 10 at the utmost <RouteResponse>-->
</Body>
</Response>
Failed route inquiry
<Response service=”RouteService”>
<Head>ERR</Head>
<ERROR code="NNNN">Detailed wrong message </ERROR>
</Response>
Failed response ：
<Response service=”RouteService”>
<Head>ERR</Head>
<ERROR code="NNNN">Detailed wrong message </ERROR>
</Response>
3.6 Route push
3.6.1 Functional description
This interface is used to push the route information of mail transporting order regularly to the customer’s system. The customer system is required to provide an HTTP URL meeting the following specification so as to benefit Shunfeng to push route data to the customer system. The pushing method shall be increment pushing. The route of a same mail transporting order shall not be repeatedly pushed.
1) Shufeng pushes data to the customer system in the way of HTTP POST;
2) Encoding format of applying method: “application/x-www-form-urlencoded; charset=UTF-8”
3) The pushed filtering results are sent to the customer system in XML format though the way of POST;
4) A POST method can push 10 filtering data at the utmost;
5) Encode XRL for the xml contents (The character set shall be UTF-8);
6) After customer system receives the inquiry, it shall firstly decode the received contents in URL and get the corresponding XML value. Then it obtains the corresponding filtering data.
7) After the customer system correctly processes XML information, it responds information to Shunfeng. Considering the processing efficiency, route push shows the success or failure of batch.
3.6.2 Definition of main messages at interface
Service name RoutePushService Batch transaction limit <=10 Interface type Push Protocol type HTTP Interface method None Data element <Request> WaybillRoute Necessary field name Type (restricted) Default value Description id Number(15) Route number, each id stands for a different route. mailno String(20) No Mail transporting order number orderid String(64) Order number accept_time Date No Route accepting time accept_address String(100) No Route accepting city remark String(300) No Route description opcode String(20) Operation code Data elements <Response > WaybillRouteResponse Field name Type (restricted) Non-empty or not Description id String(4000) No Successfully received route number, variant route numbers shall be separated by comma, like “123,124,125“ id_error String(4000) No Unsuccessfully received route number, variant route numbers shall be separated by comma, like “123,124,125“. Shunefeng will regularly send these route number.
3.6.3 Optional field message
None
3.6.4 Extended field message
None
3.6.5 Application scenario XML example
² Scenario 1
Scenario description ：
Request XML：
<Request service=”RoutePushService” lang="zh-CN">
<Head>custid（customer card number ）,checkwork（check code ）</Head>
<Body>
<WaybillRoute id=”Route number” mailno=”Mail transporting order number ” orderid=”Order number” accept_time=”Route accepting time” accept_address=”Route accepting address” remark=”Detailed description” opcode=”Operation code”/>
<!--//... 10 as the maximum value <WaybillRoute>-->
</Body>
</Request>
Response XML：
<Response service=”RoutePushService”>
<Head>OK</Head>
</Response>
4 Appendix
4.1 Reason code table
Reason code Description Classification 61** Short of necessary parameters 6101 Short of request data: indispensible items Short of necessary parameters 6102 Sender’s company name: empty Illegal verification in key field 6103 Sender’s contact personnel : empty 6104 Sender’s province : empty 6105 Sender’s city : empty 6106 Sender’s detailed information : empty 6107 Receiver’s company name: empty 6108 Receiver’s contact personnel : empty 6109 Receiver’s province : empty 6110 Receiver’s city : empty 6111 Receiver’s address : empty 6112 Receiver’s country: can’t be empty 6113 Receiver’s prince: can’t be empty 6114 Customer’s order number must be provided. 6115 Receiver’s located city name: can’t be empty 6116 Receiver’s located county/district: can’t be empty 6117 Receiver’s detailed address : can’t be empty 6118 Order number : can’t be empty 6119 Receiver’s contact telephone number: can’t be empty 6120 Express type : can’t be empty 6121 Sender’s contact telephone number: can’t be empty 6122 Illegal filtering type 6123 Mail transporting order number : can’t be empty 6124 Terms of payment: can’t be empty 6125 Producing electronic mail transporting order; cargo name can’t be empty 6126 Illegal monthly settlement account 6127 Value-added service name: can’t be empty 6128 Illegal value-added value service 8*** Function verification 8000 Illegal message parameters Invalid parameters 8001 Unauthorized IP Invalid parameters 8002 Unauthorized service (function ) 8003 Inquiring order number exceeds the maximum limit 8004 Route inquiring number exceeds the limit. 8005 Inquiring number exceeds the limit. 8006 An order has been placed. Order-confirming request cannot be received 8007 This order is confirmed. Order-confirming request cannot be received 8008 The artificial filtering order of the order has not been confirmed. Order-confirming request cannot be received 8009 This order cannot be received and delivered. Order-confirming request cannot be received 8010 This order has not been filtered. Order-confirming request cannot be received 8011 Binding relationship between the customer card number and the mail transporting order number is not established. 8012 Binding relationship between the customer card number and the order number is not established. 8013 Inquiring order number is not uploaded. 8014 Incorrect check code 8015 Mail transporting order number is not uploaded. 8016 Repeated order placing 8017 Unmatched order number and mail transporting order number 8018 Unobtained order message 8019 Conformed order 8020 Binding relationship between the order and mail transporting order does not exist. 8021 Customer card number: empty 8022 Check number: empty 8023 Service name: empty 8024 An order has not been placed. 8025 The service is not provided or does not exist. 8026 Nonexistent customers 8027 Nonexistent business template 8028 Customers fail to configure the business. 8029 Customers fail to configure default template. 8030 The legal template of this time is not found. 8031 Data error. Template is not found. 8032 Data error. Business configuration is not found. 8033 Data error. Business property is not found. 8034 Repeatedly register artificial filtering result pushing. 8035 Produce electronic mail transporting order. The mail transporting order number must be existent. 8036 Registry of route pushing must have mail transporting number. 4*** System verification 4001 System has data error or running exception. 4002 Message analysis error
世聯翻譯-讓世界自由溝通！專業的全球語言翻譯供應商，上海翻譯公司專業品牌。絲路沿線56種語言一站式翻譯與技術解決方案，專業英語翻譯、日語翻譯等文檔翻譯、同傳口譯、視頻翻譯、出國外派服務，加速您的全球交付。 世聯翻譯公司在北京、上海、深圳等國際交往城市設有翻譯基地，業務覆蓋全國城市。每天有近百萬字節的信息和貿易通過世聯走向全球！積累了大量政商用戶數據，翻譯人才庫數據，多語種語料庫大數據。世聯品牌和服務品質已得到政務防務和國際組織、跨國公司和大中型企業等近萬用戶的認可。
